Specifications

Model

PS-S02D/PS-S02E

Wireless Protocols

Wi-Fi IEEE 802.11 b/g/n 2.4 GHz, Bluetooth 4.2

Wi-Fi Operation Frequency

2412-2472 MHz

Wi-Fi Maximum Output Power

≤ 20 dBm

Bluetooth Operation Frequency

2402-2480 MHz

Bluetooth Maximum Output Power

≤ 13 dBm

Radar Operation Frequency

60-64 GHz

Radar Maximum Output Power

≤ 20 dBm (Only applicable to the EU region)

Dimensions

64 × 64 × 29.5 mm (2.52 × 2.52 × 1.16 in.)

Operating Temperature

-10°C ~ 40°C (14°F ~ 104°F)

Operating Humidity

0 ~ 95% RH, no condensation

Protection Rating

IPX5

Ports

USB-C

Input Power

5V==1A

What's in the Box

PS-S02D: Presence Sensor FP2 × 1, User Manual × 1, USB-C to USB-A Cable × 1, Metal Plate × 2, Sticker ×2, Screw Kit × 1 PS-S02E: Presence Sensor FP2 × 1, User Manual × 1, USB-C to USB-A Cable × 1, Metal Plate × 1, Sticker ×1, Screw Kit
